MODEL 655C
KEY NO. MODEL 655C
NO. PART NO. DESCRIPTION
1 97007383 Housing
2 97014185 Damper
3 98003036 Mounting Bracket (4 Req.)
4 99270981 Receptacle, White
5 99270982 Receptacle, Black
6 99270489 Receptacle, Red
7 99110446 Plastic Blower Wheel
8 99080166 Fan Motor
9 97013627 Motor Plate / Partition Assembly
10 99260428 Nut (4 Req.)
11 97016256 Grille
12 97014211 Light Reflector
13 97005316 Nut
14 99770118 Light Socket
15 97013578 Light Lens
16 97005058 Bolt Assembly
17 99020290 Blower Wheel
18 99160461 #10-24 x .375 Screw (2 Req.)
19 93260457 #10 - 32 Nut (7 Req.)
(2 included in Key No. 16)
20 99270107 Heater Hooks (5 Req.)
21 99150417 #8 x 1/4 Sheet Metal Screws (4 Req.)
22 98003788 Heater Scroll Cover
23 97005006 Heater Scroll Housing
24 99080591 Heater Motor
25 99170245 #8 x 3/8 Sheet Metal Screw
26 99160410 Grille Stud
27 98004514 Heater Element
28 99260473 Tinnerman Nut #10-24 (2 Req.)
Order service parts by "Part No. - Not by "Key No."
99045031B
BROAN-NUTONE ONE YEAR LIMITED WARRANTY
Broan-NuTone warrants to the original consumer purchaser of its products that such
products will be free from defects in materials or workmanship for a period of one year
from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MER-
CHANT ABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
During this one-year period, Broan-NuTone will, at its option, repair or replace, without
charge, any product or part which is found to be defective under normal use and service.
THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS AND
TUBES. This warranty does not cover (a) normal maintenance and service or (b) any
products or parts which have been subject to misuse, negligence, accident, improper
maintenance or repair (other than by Broan-NuTone), faulty installation or installation
contrary to recommended installation instructions.
The duration of any implied warranty is limited to the one-year period as specified for
the express warranty.
BROAN-NUTONE’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN-NUTONE’S
OPTION, SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER
THIS WARRANTY. BROAN-NUTONE SHALL NOT BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION
WITH PRODUCT USE OR PERFORMANCE.
This warranty gives you specific legal rights. This warranty supersedes all prior war-
ranties.
To qualify for warranty service, you must (a) notify Broan-NuTone at the address or
telephone number below, (b) give the model number and part identification and (c)
describe the nature of any defect in the product or part. At the time of requesting war-
ranty service, you must present evidence of the original purchase date.
Broan-NuTone Canada, Inc.
1140 Tristar Drive,
Mississauga, Ontario, Canada L5T 1H9
1-888-882-7626
SERVICE PARTS
6
GROUND (GREEN OR
BARE WIRE)
NOTCH
25
