Broan ALT2 - Page 22

INSTALLATION MANUAL SERVICE PARTS
22
ALT2 SERIES
KEY
NO.
P
ART NO.DESCRIPTION
QUANTITY
30"
B
LACK
30"
B
LACK
STAINLESS
30"
S
TAINLESS
30"
W
HITE
36"
B
LACK
36"
B
LACK
S
TAINLESS
36"
S
TAINLESS
36"
W
HITE
1
S97020029 R
ECIRC. COVER PLATE, BLACK (INCL. SCREWS)1 1
S97020030
R
ECIRCULATION COVER PLATE, WHITE
(INCLUDING SCREWS)
11
S97020031
R
ECIRC. COVER PLATE, STAINLESS STEEL
(INCLUDING SCREWS)
11
S98011873
R
ECIRCULATION COVER PLATE, BLACK
STAINLESS (INCLUDING SCREWS)
11
2 SR680508 7'' R
OUND DUCT PLATE (INCL. SCREWS)11111111
3 S97020534 3¼” X 10” DAMPER ASS’Y (INCL. SCREWS)11111111
4 S97020409
B
LOWER MOTOR (INCLUDING CAPACITOR
AND 4 SCREWS)
11 1111 11
5 S97020407 F
ANPELLER (INCLUDING ITEM 6) 11 1111 11
6 SR99420635 C
LIP FOR FANPELLER 11 1111 11
7
S99010431-002
G
REASE FILTER - MICRO MESH OBLONG
-TYPE C3 (SET OF 2)
11 11
S99010431-003
GREASE FILTER - MICRO MESH OBLONG
-TYPE D3 (SET OF 2)
11 11
8 S97020444 LED
MODULE (PAIR) 11 1111 11
9 S97020445 T
RANSFORMER 24 V 18 VA (WITH SCREWS)11111111
10
S97020431
C
APTOUCH CONTROL LED,
STAINLESS (WITH SCREWS)
11
S97020432
C
APTOUCH CONTROL LED, WHITE
(WITH SCREWS)
11
S97020433
C
APTOUCH CONTROL LED, BLACK
(
WITH SCREWS)
11 11
* S97020452 W
IRE HARNESS 11 1111 11
* S98011637 W
IRING COVER 11 1111 11
* S97020360
P
ARTS BAG INCLUDING: 4 METAL SCREWS
NO
. 8-18 X 1/2”, 6 ROUND HEAD
NO. 8 X 5/8” WOOD SCREWS, 6 NO. 8 X 1/2”
COUNTERSUNK WOOD SCREWS
11 1111 11
*
S97020466
N
ON-DUCTED F ILTER - TYPE XC ( SET OF 2)
(
NON-DUCTED INSTALLATION ONLY)
11 11
S97020467
N
ON-DUCTED F ILTER - TYPE XD ( SET OF 2)
(
NON-DUCTED INSTALLATION ONLY)
11 11
* S99527587 NON-DUCTED FILTER CLIP KIT (INCL. 4 CLIPS)11111111
* S97020470 E
ASY INSTALL KIT (INCL. HARDWARE)11 11 1 11
* ITEM NOT SHOWN.
REPLACEMENT PARTS AND REPAIRS
In order to ensure your unit remains in good working condition, you must use Broan-NuTone LLC or Venmar Ventilation ULC genuine
replacement parts only. Broan-NuTone LLC or Venmar Ventilation ULC genuine replacement parts are specially designed for each
unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety. Any third
party replacement part used may cause serious damage and drastically reduce the performance level of your unit, which will result in
premature failing. Broan-NuTone LLC and Venmar Ventilation ULC recommend to contact a certified service depot for all replacement
parts and repairs.
E
J
K
B
C
D
F
G
H
I
