Broan ALT2 - Page 23

INSTALLATION MANUAL
SERVICE PARTS
23
ALT1 SERIES
KEY
NO.
P
ART NO.DESCRIPTION
QUANTITY
30"
B
LACK
30"
S
TAINLESS
30"
W
HITE
36"
B
LACK
36"
S
TAINLESS
36"
W
HITE
1
S97020029 R
ECIRCULATION COVER PLATE, BLACK (INCLUDING SCREWS)1 1
S97020030 R
ECIRCULATION COVER PLATE, WHITE (INCLUDING SCREWS)1 1
S97020031 R
ECIRC. COVER PLATE, STAINLESS STEEL (INCL. SCREWS)1 1
2 SR680508 7'' R
OUND DUCT PLATE (INCLUDING SCREWS) 111111
3 S97020534 3¼”
X 10” DAMPER ASSEMBLY (INCLUDING SCREWS) 111111
4 S97020408 B
LOWER MOTOR (INCLUDING CAPACITOR AND 4 SCREWS)111111
5 S97020407 F
ANPELLER (INCLUDING ITEM 6) 111111
6 SR99420635 C
LIP FOR FANPELLER 111111
7
S99010434-002 G
REASE FILTER - MICRO MESH -TYPE C2 (SET OF 2) 1 1 1
S99010434-003 G
REASE FILTER - MICRO MESH -TYPE D2 (SET OF 2) 1 1 1
8
S99030367 R
OCKER SWITCH, GREY (SET OF 2) 1 1
S99030355 R
OCKER SWITCH, WHITE (SET OF 2) 1 1
S99030356 R
OCKER SWITCH, BLACK (SET OF 2) 1 1
9 SV05921 S
HIELDED HALOGEN BULBS 50 W GU10 2 2 2 2 2 2
* S97020448 W
IRE HARNESS 111111
* S98011637 W
IRING COVER 111111
* S97020292
P
ARTS BAG INCLUDING: 4 METAL SCREWS NO. 8-18 X 1/2”,
6 R
OUND HEAD NO. 8 X 5/8” WOOD SCREWS, 6 NO. 8 X 1/2”
C
OUNTERSUNK WOOD SCREWS, 1 SUCTION CUP TOOL
111111
*
S97020466
N
ON-DUCTED FILTER - TYPE XC (SET OF 2)
(
NON-DUCTED INSTALLATION ONLY)
111
S97020467
N
ON-DUCTED FILTER - TYPE XD (SET OF 2)
(
NON-DUCTED INSTALLATION ONLY)
111
* S99527587 N
ON-DUCTED FILTER CLIP KIT (INCL. 4 CLIPS) 111111
* S97020470 E
ASY INSTALL KIT (INCLUDING HARDWARE) 111111
* I
TEM NOT SHOWN.
B
C
D
E
F
G
I
J
H
REPLACEMENT PARTS AND REPAIRS
In order to ensure your unit remains in good working condition, you must use Broan-NuTone LLC genuine replacement parts only. Broan-
NuTone LLC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable
certification standards and maintain a high standard of safety. Any third party replacement part used may cause serious damage and
drastically reduce the performance level of your unit, which will result in premature failing. Broan-NuTone LLC recommends to contact a
certified service depot for all replacement parts and repairs.
