SERVICE PARTS
Models 2730 & 2736 Downdraft Blower Systems
6
OPTIONAL DOOR KITS
*Standard Hardware - May be purchased locally.
**Service Assembly - Contains numerous parts.
MODEL NO. DESCRIPTION
273001C 30" White
273002C 30" Biscuit
273023C 30" Black
273601C 36" White
273602C 36" Biscuit
273623C 36" Black
KEY NO. PART NUMBER DESCRIPTION QTY.
1 93400038 Bushing, 7/8” 1
2 99400061 Bushing, Split Heyco, 5/8” 1
3 99400024 Bushing, Heyco, 1/2” 1
4 99470016 Roller 1
5 97011238 Switch Assembly, Up/Down 1
6 97010714 Wire Harness, Speed Control 1
7 99260491 Nut, 3/8-32 1
8 99360165 Knob 1
9 99100484 Motor Insolator 3
10 97009972 Lower Switch Bracket Assembly 1
11 97011293 Green Ground Wire 1
12 97010993 Wire Harness 1
16 98007642 Back-up Plate 1
17 98007780 Crank 1
18 98010813 Switch Cover 1
19 98018523 Chimney Assembly (Model 2730) (Includes 1
Key Nos. 5, 8, 19, 45, 51, 52, 71 & 84)
98018524 Chimney Assembly (Model 2736) (Includes 1
Key Nos. 5, 8, 19, 45, 51, 52, 71 & 84)
20 99080362 Motor (with Capacitor-Key No. 73) 1
21 99020247 Blower Wheel 1
22 98010810 Scroll Box Extension 1
23 99710032 Spacer 3
24 97011259 Top Bracket Assembly, Right 1
25 97011260 Top Bracket Assembly, Left 1
26 97011322 Top, Stainless (Model 2730) 1
97011323 Top, Stainless (Model 2736) 1
28 97018476 Scroll Box Assembly 1
29 97011443 Gear Motor Cover 1
30 97010994 Air Box Assembly (Model 2730) 1
97010992 Air Box Assembly (Model 2736) 1
31 98010809 Scroll Box Cover 1
32 98008157 Capacitor Strap 1
33 97009786 Filter Kit (Model 2730) (contains 2 filters) 1
97009787 Filter Kit (Model 2736) (contains 2 filters) 1
45 99090905 End Cap 1
46 99080590 Gearmotor 1
47 99110850 Slide Strip 4
49 99170245 Screw, #8-18 x .375 SLT HX WS HD 19
50 99150471 Screw, #10-32 x .500 HX WS BDRH 2
51 99150491 Screw, #8-18 x .375 SR PH TRH 6
52 99150488 Screw, #8-18 x .500 No. 5 PH Trim 2
53 98010802 Cover, Air Box Opening (Model 2730) 1
98010803 Cover, Air Box Opening (Model 2736) 1
54 99260488 Nut, #10-24 4
55 98010822 Air Box Cover (Model 2730) 1
98010823 Air Box Cover (Model 2736) 1
56 97011500 Gearmotor Bracket Assembly 1
57 98008159 Leg Support 2
58 99150536 Screw, 1/4-20 x 5/16
5
59 99250927 Washer, 1/4 2
60 99150479 Screw, #8-32 x 1/2 PH HD MS 4
61 99160356 Screw, #10-24 x 3/8 SH WH LOCK 1
62 99160361 Screw, #10-24 x 3/8 PH FL HD LD 1
64 99260437 Nut, 10-24 HEX KEPS 7
65 99260477 Nut, 1/4-20 WHIZ LOCK 3
66 99380633 U-Bolt, 10-24 1
67 99400048 Strain Relief 1
68 93260447 Nut, Hex Flange 1
70 98010804 Airbox Clamp 2
71 93270493 Wire Tie 3
73 99271000 Capacitor 1
74 99160384 Screw, 1/4-20 x 2.000 HEX HD 2
75 99150415 #8-18 x .250 PH TR HD BPT 2
84 99100544 Seal - Foam (30”) 1
99100545 Seal - Foam (36”) 1
** 97018534 Blower Assembly, Complete (Includes Key
Nos.2, 9, 20, 21, 22, 28, 31, 32, 49, 58, 64,
65 & 73)
Replacement parts can now be
ordered on our website.
Please visit us at www.Broan.com
