Broan PK22 - Service Parts Identification; Replacement Part Numbers

- 20 -
KEY NO. PART NO. DESCRIPTION
6 B02000191 Filter Spring
9 B08087305 Grease Filter
14 B02300653 Motor Capacitor
26 B02300668 Halogen Lamp Bulb
38 B03292357 Control Board Box
39 B03294033 Control Board Box Cover
45 B03100016 Blower
48 B02310036 Motor
49 B03292284 Blower Wheel
50 B02000314 Blower Bracket
53 B03202007 Rubber Washer
107 B03202287 Cable Stop
115 BE3334250 Wiring Box
116 BE3334252 Wiring Box Cover
144 B03292287 Wire Clamp
147 BR2300132 Junction Clamp
154 B03202286 Fairlead
165 B03292358 Control Box
166 B08086141 Circuit Board
167 B03292162 Control Box Cover
168 B03292163 Capacitor Box Cover
195 BE3401302 Lamp Support (90 cm models)
195 BE3401305 Lamp Support (120 cm models)
196 BE3332407 Reflector (90 cm models)
196 BE3332415 Reflector (120 cm models)
199 B02300688 Ceramic Insulator
200 B02009103 Lamp Protection
208 B02300670 Transformer
230 B03292937 Switch Board Box Cover
250 B02009102 Ring Nut
415 B03202288 Lead (90 cm models)
415 B03292169 Lead
* B06001882 Blower Assembly
(Includes Key Nos. 45, 48, 49, 50, 53)
* B06107298 Switch Box Assembly (90 cm models)
(Includes Key Nos. 222, 223, 224, 225, 226,
227, 229, 230)
* B06105580 Switch Box Assembly (120 cm models)
(Includes Key Nos. 222, 223, 224, 225, 226,
227, 229, 230)
* B08085018 Ductfree Collar Assembly
(Includes Key Nos. 56, 57)
* Not shown assembled.
SERVICE PARTS
MODEL PK22
