Broan ZB80 - Retrofit: Remove Blower Assembly; Retrofit: Remove Wiring Panel; Retrofit: Install Mounting Frame

ZB80
n
ZB110 Installation Guide
Page 8
2
1
2
3
4
5
1
1
2
3
3
Retrofit Installation
5
Remove Blower Assembly
6
Remove Wiring Panel
7
Insert
Mounting
Frame
Both sides
Set aside
Blower Assembly
Set aside
Wiring Panel
Set aside
screw
Bend up
four tabs
Remove screws from
Mounting Frame
and set aside
