6
Step 4
Undo the hinge clamp and swing the handlebars down alongside the front wheel and engage in the clip;
alternatively, let the handlebar drop into position on its own.
Step 5
Rotate the crank so that the right
hand pedal touches the front
wheel.
Step 6
Press the outer part of the pedal
latch plate downwards, so that it
clears the top of the pedal, and fold
the pedal.
Note:
1. When folded, the seat pillar locks the folded package together; the Lower Stop Disc acts as both a guide
and a block to prevent the rear frame from rotating, and must be correctly adjusted to ensure it fulfils
both functions.
2. Carry your Brompton by gripping the front of the saddle or the main frame.
3. The left hand pedal should not be folded when turning the cranks, as it can catch on parts of the rear
frame and cause damage to your bike.
