FOLDING
Step 1
Release the rear frame clip (if the rear frame is locked in place) by pushing the lever towards the front
of the bike. Then raise the bike by the saddle, allowing the rear wheel to swing down and forward to lie
under the main frame as pictured.
Please ensure that the right hand pedal (chain side) points backwards once the wheel is folded under the
main frame, as pictured.
Step 3
Undo the quick release lever and push the seat pillar and saddle down. Tighten the quick release lever; it
should be wrapped around the outside of the seat pillar, touching the frame in its closed position.
5
English
Step 2
Unscrew the hinge clamp on the main frame (about 4 turns). Grip the handlebar support, pushing back
on the saddle at the same time and, using a “stirring” motion, move it around until it lies alongside the
rear wheel. Make sure the hook engages the tube on the rear frame.
