14
Power selector switches (16 and 18) make it possible to individually reduce the energy level per
channel by up to two further f-stops. When both lamp outlets (14.2 and 14.3) are active, the energy
per lamp on channel 2 can be reduced to 13 joule/26.5 joule (A2/A4).
4.6 Power distribution tables (Senso A2 and A4)
4.6.1 Symmetric mode
(one lamp connected to any lamp outlet)
Channel 1,
rocker switch (1)
on setting
Channel 2,
rocker switch (3)
on setting
Control range
by means of keys
Senso A2 and A4
Power
in joules
Senso A2
Power
in joules
Senso A4
1/1 1/1 8.0 - 10 300 - 1200 600 - 2400
1/1 1/2 7.6 - 9.6 227 - 900 450 - 1820
1/1 1/4 7.3 - 9.3 184 - 750 369 - 1500
1/2 1/2 7.0 - 9.0 150 - 600 300 - 1200
1/2 1/4 6.6 - 8.6 113 - 450 227 - 900
1/4 1/4 5.5 - 8.0 53 - 300 106 - 600
4.6.2 Asymmetric mode
(one lamp per channel)
Channel 1 or 2,
rocker switch (1 or 3)
on setting
Control range
by means of keys
Senso A2 and A4
Power in joules
Senso A2
Power in joules
Senso A4
1/1 7.0 - 9.0 150 - 600 300 - 1200
1/2 6.0 - 8.0 75 - 300 150 - 600
1/4 4.5 - 7.0 26.5 - 150 53 - 300
4.6.3 Asymmetric mode
(2 lamps on channel 2)
Channel 2,
rocker switch (3)
on setting
Control range
by means of keys
Senso A2 and A4
Power in joules
per lamp
Senso A2
Power in joules
per lamp
Senso A4
1/1 7.0 - 9.0 75 - 300 150 - 600
1/2 6.0 - 8.0 37.5 - 150 75 - 300
1/4 4.5 - 7.0 13 - 75 26.5 - 150
