1. APPLICATION OF BRONCOLOR SENSO POWER PACK
This mains (AC-line) supplied studio flash unit is designed for professional photography. When
using an extension cable, for your safety, use a three-wire extension cable when possible.
2. START UP
2.1 Mains voltage
As a standard feature, all the Senso power packs are supplied as multi-
voltage units. Ensure that the mains selector switch (19) is set to the
correct voltage.
Senso power packs A2 and A4 supply for operating voltages 100-240 V,
a constant 1200 J or 2400 J.
Attention: Ensure that the operating voltage of the modelling lamp corresponds to the local
mains supply (max. 650 W on 200-240 V or 300 W on 100-120 V). The modelling lamp protection
function (L120) is also available, which is described in detail in section 9.5.
2.2 Earthed mains (AC-line)
Whenever possible, connect unit to current supply always using an earthed mains plug.
2.3 Start up
Use the mains (AC-line) switch (12) to power up the unit. During the charging process, the corres-
ponding digital power distribution display (15 and 17) blinks, after which, it becomes continuous. If
no lamp is connected “----“ appears in the display (15 and 17).
