3
J1/J1-1/J1-2/J1-3 USB connector
Choose one USB interface with a corresponding USB
extension cable for the connection.
* Please double-check whether the corresponding pin order is correct.
Improper connection may cause the fighting board to burn.
VDD_5V GND 3K / R2 / RT 1K / X / A 4P / L1 / LB 2P / / Y START / OPTIONS SELECT / SHARE / BACK RIGHT UP
VDD_5V
GND
4K / L2 / LT
2K / / B
GND
3P / R1 / RB
1P / / X
HOME / PS / XB
LEFT
DOWN
GND
D+
D‒
VDD_5V
GND
GND
D+
D‒
VDD_5V
G D+ D- V
J1-1、J1-2
Red
White
Green
Black
G
D+
D-
V
Red
White
Green
Black
J1-3
EN
TW
JP
KR
