Mode 0: LR Cancel & Up Priority (Default)
Mode 1: Second-Input Priority (SIP)
J2 SOCD resolution mode selection
J2
Mode 0
Open circuit
J2
Mode 1
Short circuit
J5 Player LED Guide
PS4Player
1P
2P
3P
4P
5P
6P
7P
PS3 Xbox One Xbox 360
LED ON LED OFF
