Brook XB Fighting Board - Analog Stick and Button Wiring; Analog Stick Connection (J1;J9); Digital Input Connections (J2;J4;J13)

3
J1/J9: Connecting analog stick
J9
J9
Removed
Installed
Enable
Disable
J9
Remove
Jumper
Step 1. Step 2.
J1
L-Stick
R-Stick
VCC
LSB
GND
RSB
RY
RX
LY
LX
As J2 and J4 have the same functions, only one of them is needed for
the connection, it is recommended to use the dedicated cable
"BROOK Fighting Board Cable".
J2/J4/J13: Connecting buttons and digital joystick
J2 pin names
19
20
1
2
VCC GND RT A LB Y
RIGHT UP
MENU VIEW
VCC
GND
LT
B
GND
RB
GUIDE
LEFT
DOWN
X
J2
J4 pin names
J6-1
GND D+ D- VDD_5V
1
1
XB
J5
DP
LS
LT RT B A GND LB RB Y X MENU VIEW GUIDE GND GND RIGHT LEFT UP DOWN VDD_5V GND
SOCD
J11J6
J4
1
P4
P3
P2
P1
VCC
EN
JP
TW
