J5: LS/DP/RS ON/OFF switch
DP Mode (default): Joystick input corresponds to D-Pad output.
LS Mode: Joystick input corresponds to Left 3DVR(Lx/Ly) output.
RS Mode: Joystick input corresponds to Right 3DVR(Rx/Ry) output.
If the analog stick (J9 short circuit) and ON/OFF switch (J5: DP
mode) are not needed, press the following button combinations
for 3 seconds to change the joystick input mode.
＊When successfully switched, all Player LED will go dark for 1 second.
= L-Stick
= D-Pad
= R-Stick
+
+
+
4
J3: Key lock
You can turn o the dierent functions that may be determined as
illegal in ocial competitions,include: Guide, Menu, and View buttons.
When the LOCK LED is on, it means that the key function lock is on.
When the LOCK LED is o, it means that the key function lock is o.
EN
JP
TW
XB
19
20
1
2
J2
J5
J1
RS
DP
LS
VCC
LSB
GND
RSB
RY
RX
LY
LX
GND
LT
RT
B
A
GND
LB
RB
