5
locaTIon of PaRTs anD conTRols
1. Battery Compartment End Cap
2. Handle
3. Charging Indicator Light
4. Charging Port
(under Rubber Ring)
5. Rubber Ring
6. Lens
7. Charging Jack
8. Charging Adapter
9. Face Cap/Bulb Access
10. On/Off Button
chaRGInG
Important: The flashlight battery must be charged for 8 hours before first use.
1. Ensure that the flashlight is off.
2. Twist the RUBBER RING so the CHARGING PORT is accessible.
The CHARGING PORT is located directly above the CHARGING INDICATOR
LIGHT. See next page for part locations.
8
9
6
10
4
3
2
1
7
5
