Brookstone Rover Revolution - Location of Parts and Controls

6 7
LOCATION OF PARTS AND CONTROLS (ROVER REVOLUTION)
1. Antenna
2. Night Vision Lens
3. Rotating Spy Camera
4. White Power LED
5. Microphone
6. Green Connection LED
7. Night Vision Lens
8. Driving Camera
9. Wheel (4)
10. Headlights (2)
11. Lighted Coils (2)
12. Tail Lights (2)
851135_INS0913_Rover Revolution_Size:5”Wx4.75”H_Output:100%_Prints:1/1,Blk
13. SSID Number
14. Reset Button
15. Charging Port
16. Battery Compartment
17. Battery Compartment
Access Screw
18. Charging LED
19. Power Switch
20. Trim Adjustment
LOCATION OF PARTS AND CONTROLS (ROVER REVOLUTION)
18
17
15
20
16
19
14
13
3
1
10
2
4
6
7
8
9
5
11
12
