Brose drive unit 45 km/h
Brose material number C79232/C97292
Dimensions 213x150x128 mm
Weight 3.400g
Nominal voltage 36 V
Protection class IP56
Torque max. 90nm
Continuous rated power 250 W
Starting aid to 20 km/h
Pushing aid to 6 km/h
Lighting for drive version C16162 / C9143 / C79232 /
C97292
Nominal voltage 6 V
Maximum rated power*
- Front light
- Rear light
6,6 W
0,6 W
Lighting for drive version C97272
Nominal voltage 6 V
Maximum rated power*
- Front light
- Rear light
14,0 W
0,6 W
* Please check by means of the item number on
the drive unit which drive version has been instal-
led in your e-bike.
General Brose drive maintenance instruc-
tions:
General Brose drive maintenance instructions:
Your Brose motor is equipped with a toothed
belt. Toothed belts are subject to a certain
degree of wear and tear. It is therefore
important that you have the toothed belt repla-
ced by a certified specialist dealer after 10,000
km of driving. Otherwise failures and injuries
may occur.
