4
WARNING !!!
DO NOT HIT THE CASTING DIRECTLY - IF THE FRONT PLATE IS STILL NOT SECURE
CHECK THE LOCATION AND SEATING OF THE FRONT PLATE AND LOCATION OF THE
CATCHES AND PINS - THIS IS A SIMPLE AND STRAIGHT FORWARD OPERATION AND
EXCESSIVE FORCE MUST NOT BE USED.
The Front Plate will be easier to handle if the Doors are taken off by removing the Fixing Pins which
can be tapped out from underneath the Hinge Blocks.
It is convenient at this stage to use a ‘gun’ applicator of fire cement to form a vertical ‘fillet seal’ at
the internal junctions between the leading vertical edges of the Non-Boiler/Boiler Unit and the Front
Plate and a horizontal ‘fillet seal’ at the internal junction of the Base Plate and the Front Plate.
Fit the Fire Chamber Steel Plate Panels (Non-Boiler Models only)
The Fire Chamber Panels are fitted by locating the top edge behind the down standing face of the
top retaining rail, lifting and dropping so that the bottom edge is located behind the upstanding face
of the bottom retaining rail.
Note on fitting:
The panel with the large cut-out fits around the afterburner.
The panel with a cut ledge fits along the rear on the left side.
The narrow panel fits along the rear.
The other two panels (smaller than the rest) fit left and right.
Fit the Baffle Plate
Place the Baffle Plate on the supporting brackets. The bracket on the baffle faces the base of the
stove.
Fit the Fire Grates
Place the two half Fire Grates on the supporting ledges (ribbed face underside).
Fit the Fret Rails
Place the first Fret Rail with the flat ash deflector bar between the back face of the Front Plate and
the steel Retaining Plates.
Place the second and third Fret Rails on top of the first Fret Rail
The notched ends of the Fret Rails face inwards and are loose fitting.
Fit the two Ash Pans
Place the Ash Pans side-by-side in the ash-pan compartment below the Grates.
Fit the Top Plate
Place the Top Plate onto the stove body and check that it is centrally located and seated onto the
wide recessed rope seal. The Top Plate relies upon self-weight to seal (do not use fire cement to
seal).
To dismantle the stove, follow the above sequence in reverse.
IMPORTANT NOTICE !!!
It is essential that the chimney is of sound construction and swept clean before fitting the
stove.
IF IN DOUBT - CHECK IT OUT (Contact a Flue Specialist or Experienced Chimney Sweep)
