44
After hooping the fabric in the embroidery frame, attach the frame to the embroidery machine.
Attaching the embroidery frame
Adjust the width of the embroidery frame holder to the size of the embroidery frame, and then attach the
embroidery frame to the machine. As an example, the procedure for attaching the medium embroidery
frame is described below.
1 Left arm of embroidery frame holder
Move the arm of the embroidery frame holder to
the left or right to adjust it to the size of the
embroidery frame.
2 Clip on embroidery frame holder.
Insert the embroidery frame into the clips on the
embroidery frame holder.
3 Positioning pin
4 Holes
5 Positioning slots
a
Loosen the two thumb screws on the
embroidery frame holder.
If the screw is too tight, please use the included disc-
shaped screwdriver.
1 Left arm
2 Thumb screws
→ The left arm of the embroidery frame holder can be
moved.
• Only loosen the thumb screws a maximum of 2 turns
counterclockwise. Do not remove the screw.
8. Attaching the Embroidery Frame to the Machine
• If the embroidery frame is not correctly attached, it may hit the presser foot and damage the machine, or
cause injury to the user.
• When attaching the embroidery frame, make sure that the “Start/Stop” button is lit in red. If the “Start/
Stop” button is flashing in green, the embroidery machine may start embroidering. If the embroidery
machine accidentally starts operating, injuries may result.
• When attaching the embroidery frame, make sure that the embroidery frame does not hit any other part of
the embroidery machine.
• Before attaching the embroidery frame, check that there is enough thread in the bobbin.
