Brother DCP-L2510D User Manual

2-100
Confidential
4.6 Troubleshooting for Control Panel Problems
4.6.1 Nothing is displayed on the LCD
<User Check>
• Turn the power switch OFF and then back ON again.
• Unplug the AC cord and then plug it again.
4.6.2 Nothing is displayed on the LED
<User Check>
• Turn the power switch OFF and then back ON again.
4.6.3 Unable to perform panel operation
<User Check>
• Turn the power switch OFF and then back ON again.
Step Cause Remedy
1
Connection failure of the
panel flat cable
Reconnect the panel flat cable.
2
Connection failure of the low-
voltage power supply harness
Reconnect the low-voltage power supply
harness.
3
Connection failure of the LCD
flat cable
Reconnect the LCD flat cable.
4 AC cord failure Replace the AC cord.
5 Panel flat cable failure Replace the panel flat cable.
6 LCD failure Replace the panel unit.
7 Panel PCB ASSY failure Replace the panel PCB ASSY.
8
Low-voltage power supply
PCB failure
Replace the low-voltage power supply PCB
ASSY.
9 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the key
PCB flat cable
Reconnect the key PCB flat cable.
2 Panel flat cable failure Replace the panel flat cable.
3 Key PCB failure Replace the key PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the panel
flat cable
Reconnect the panel flat cable.
2
Connection failure of the touch
panel flat cable
Reconnect the touch panel flat cable.
3
Connection failure of the key
PCB flat cable
Reconnect the key PCB flat cable.
4 Panel PCB failure Replace the panel PCB ASSY.
5 Key PCB failure Replace the key PCB ASSY.
6 Touch panel ASSY failure Replace the panel unit.
7 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L2510D Specifications

General

N-up printing	2, 4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Duplex print speed (black, normal quality, A4/US Letter)	7.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	30 cpm
Scan to	E-mail, File, Image, OCR
Input color depth	30 bit
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Internal memory	64 MB
Sound pressure level (quiet mode)	44 dB
Display	LCD
Product color	Black
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	60 - 230 g/m²
Direct printing	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Package depth	517 mm
Package width	580 mm
Package height	434 mm
Package weight	13100 g
Power consumption (off)	0.03 W
Power consumption (sleep)	6.2 W
Power consumption (standby)	42 W
Power consumption (PowerSave)	260 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	1.232 kWh/week
Noise level	48 dB
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Included cartridge capacity (black)	700 pages
Total input capacity	250 sheets
Total output capacity	120 sheets
Maximum duty cycle	- pages per month
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	399 mm
Width	410 mm
Height	272 mm
