Page #146 background image
2-106
Confidential
4.11.3Document jam
Paper jam in the ADF cover
<User Check>
Check that the thickness of the document is 64 to 105 g/m
2
.
Check that the paper used for the document is not shorter than 147.3 mm.
Check that the ADF cover is closed correctly.
Check that the number of paper set has not exceeded the upper limit in the document tray.
Paper jam in the ADF
<User Check>
Check that the thickness of the document is 64 to 105 g/m
2
.
Check whether the document is smaller or larger than the specifications.
Check whether the document is wet or wrinkled.
Check that the document guide is adjusted to suit the document size.
Step Cause Remedy
1
Foreign object inside the area
around ADF cover
Remove the foreign object.
2
Document pinch roller 1
coming off
Reattach the document pinch roller 1.
3 Damaged ADF drive gear Replace the ADF unit.
4 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Foreign object inside the ADF Remove the foreign object.
2
Document scanning position
actuator coming off
Reattach the document scanning position
actuator.
3
Document pinch roller 2
coming off
Reattach the document pinch roller 2.
4
Connection failure of the
document scanning position
sensor harness
Check the connection of the document
scanning position sensor harness, and
reconnect it if necessary.
5
Second side document hold
coming off
Reattach the second side document hold.
6
First side document hold
coming off
Reattach the first side document hold.
7
Fed at an angle and jammed
due to abrasion of document
separate roller
Replace the document separate roller ASSY.
8
Document scanning position
sensor failure
Replace the ADF unit.
9 Main PCB failure Replace the main PCB ASSY.
