Brother DCP-L2540DN How To Replace Drum Unit

- 3 -
6
Go to http://www.brother.com/original/index.html for instructions on how to return your used supplies to the Brother collection program. If you choose not to return your
used supply, please discard the used supply according to local regulations, keeping it separate from domestic waste. If you have questions, call your local waste disposal
ofce.
[ English ] RESET THE DRUM UNIT COUNTER
Make sure the machine is turned on.
<For HL-L2300D/HL-L2320D/HL-L2321D>
(1) Make sure that the front cover is open.
(2) Press and hold Go for about four seconds until all of the LEDs
light up. Once all four LEDs are lit, release Go.
(3) Close the front cover.
(4) Make sure the Drum LED is now off.
<For HL-L2305W/HL-L2340DW/HL-L2360DN/HL-L2360DW/
HL-L2361DN/HL-L2365DW/HL-L2366DW>
(1) Make sure that the front cover is open.
(2) Press and hold OK for about two seconds to display
Drum Unit, and then press OK.
(3) Press a to display Reset and reset the drum counter.
(4) Close the front cover.
<For DCP-L2500D/DCP-L2520D/DCP-L2520DW/DCP-L2540DN/
DCP-L2540DW/DCP-L2541DW/MFC-L2680W/MFC-L2700D/
MFC-L2700DN/MFC-L2700DW/MFC-L2705DW/MFC-L2707DW/
MFC-L2701D/MFC-L2701DW/MFC-2703DW>
(1) Make sure that the front cover is open.
(2) Press and hold OK for about two seconds to display
Replace Drum?.
(3) (DCP models) Press a to reset the drum counter.
(MFC models) Press 1 to reset the drum counter.
(4) Close the front cover.
<For HL-L2380DW/DCP-L2560DW/MFC-L2720DW/MFC-L2740DW>
(1) Close the front cover.
(2) Press
to interrupt the error.
(3) Press
(Settings) > All Settings > Machine Info. >
Parts Life.
(4) Press # until the Touchscreen message changes.
(5) Press Drum, and then press Yes.
(6) Press
.
6
Unter http://www.brother.com/original/index.html nden Sie Anweisungen, wie Sie die Verbrauchsmaterialien im Rahmen des Brother Recyclingprogramms zurücksenden
können. Wenn Sie sich gegen die Rücksendung der Verbrauchsmaterialien entscheiden, entsorgen Sie die Verbrauchsmaterialien gemäß den örtlichen Bestimmungen
getrennt vom normalen Hausmüll. Wenn Sie Fragen haben, wenden Sie sich an Ihren örtlichen Wertstoffhof.
[ Deutsch ] Setzen Sie den ZÄHLER DER TROMMELEINHEIT zurück
Stellen Sie sicher, dass das Gerät eingeschaltet ist.
<Für HL-L2300D/HL-L2320D/HL-L2321D>
(1) Stellen Sie sicher, dass die vordere Abdeckung geöffnet ist.
(2) Halten Sie Go (Los) ca. vier Sekunden lang gedrückt, bis alle
LEDs aueuchten. Wenn alle vier LEDs leuchten, lassen Sie
Go (Los) wieder los.
(3) Schließen Sie die vordere Abdeckung.
(4) Stellen Sie sicher, dass die Drum (Trommel)-LED nun aus ist.
<Für HL-L2340DW/HL-L2360DN/HL-L2360DW/HL-L2361DN/
HL-L2365DW/HL-L2366DW>
(1) Stellen Sie sicher, dass die vordere Abdeckung geöffnet ist.
(2) Halten Sie OK ungefähr zwei Sekunden lang gedrückt, bis
Trom mel angezeigt wird. Drücken Sie dann OK.
(3) Drücken Sie a, um Reset anzuzeigen, und setzen Sie dann
den Trommelzähler zurück.
(4) Schließen Sie die vordere Abdeckung.
<Für DCP-L2500D/DCP-L2520D/DCP-L2520DW/DCP-L2540DN/
DCP-L2540DW/DCP-L2541DW/MFC-L2700D/MFC-L2700DN/
MFC-L2700DW/MFC-L2701D/MFC-L2701DW/MFC-2703DW>
(1) Stellen Sie sicher, dass die vordere Abdeckung geöffnet ist.
(2) Halten Sie OK ungefähr zwei Sekunden lang gedrückt, um
Trommel ersetzt? anzuzeigen.
(3)
(DCP-Modelle) Drücken Sie a, um den Trommelzähler zurückzusetzen.
(MFC-Modelle) Drücken Sie 1, um den Trommelzähler zurückzusetzen.
(4) Schließen Sie die vordere Abdeckung.
<Für HL-L2380DW/DCP-L2560DW/MFC-L2720DW/MFC-L2740DW>
(1) Schließen Sie die vordere Abdeckung.
(2) Drücken Sie
, um den Fehler zu abzubrechen.
(3) Drücken Sie
(Ei nstell.) > Alle Einstell. >
G e r äte-I n fo > Teilelebensdauer.
(4) Drücken Sie #, bis sich die Meldung im Touchscreen-Display
ändert.
(5) Drücken Sie Trommel, und drücken Sie dann Ja.
(6) Drücken Sie
.
6
Voir http://www.brother.com/original/index.html pour savoir comment retourner vos consommables usagés dans le cadre du programme de collecte Brother. Si vous ne
renvoyez pas votre consommable, mettez-le au rebut conformément aux réglementations locales en vigueur, en le séparant des ordures ménagères. Si vous avez des
questions, appelez les autorités locales compétentes en la matière.
[ Français ] RÉINITIALISEZ LE COMPTEUR DU TAMBOUR
Assurez-vous que l’appareil est sous tension.
<Pour HL-L2300D/HL-L2320D/HL-L2321D>
(1) Assurez-vous que le capot avant est ouvert.
(2)
Appuyez sur la touche Go (Démarrer) et maintenez-la enfoncée
pendant environ 4 secondes jusqu’à ce que les DEL s’allument.
Une fois les 4 DEL allumées, relâchez la touche Go (Démarrer).
(3) Fermez le capot avant.
(4) Assurez-vous que la DEL Drum (Tambour) est maintenant
éteinte.
<Pour HL-L2340DW/HL-L2360DN/HL-L2360DW/HL-L2361DN/
HL-L2365DW/HL-L2366DW>
(1) Assurez-vous que le capot avant est ouvert.
(2)
Maintenez la touche OK enfoncée pendant environ deux
secondes pour afcher l’option Tam bour, puis appuyez sur OK.
(3) Appuyez sur a pour afcher Init. et remettre le compteur du
tambour à zéro.
(4) Fermez le capot avant.
<Pour DCP-L2500D/DCP-L2520D/DCP-L2520DW/DCP-L2540DN/
DCP-L2540DW/DCP-L2541DW/MFC-L2700D/MFC-L2700DN/
MFC-L2700DW/MFC-L2701D/MFC-L2701DW/MFC-2703DW>
(1) Assurez-vous que le capot avant est ouvert.
(2) Maintenez OK enfoncé pendant deux secondes environ pour
afcher Changer tambour?.
(3)
(Modèles DCP) Appuyez sur a pour remettre le compteur du tambour à zéro.
(Modèles MFC) Appuyez sur 1 pour remettre le compteur du tambour à zéro.
(4) Fermez le capot avant.
<Pour HL-L2380DW/DCP-L2560DW/MFC-L2720DW/MFC-L2740DW>
(1) Fermez le capot avant.
(2) Appuyez sur
pour mettre n à l’erreur.
(3) Appuyez sur
(Réglages) > Ts params >
Info. appareil > Durée de vie des pièces.
(4) Appuyez sur # autant de fois que nécessaire pour changer le
message afché sur l’écran tactile.
(5) Appuyez sur Tambour, puis sur Oui.
(6) Appuyez sur
.
Finish
Fertig
Terminer

Brother DCP-L2540DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Duplex print speed (color, normal quality, A4/US Letter)	6.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 6, 9, 16, 25
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	26 cpm
Scan to	E-mail, File, FTP, Image, OCR
Scan drivers	ICA, SANE, TWAIN, WIA
Grayscale levels	256
Input color depth	30 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Faxing	No
PCL fonts	66
Printing colors	Black
Maximum duty cycle	10000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, GDI, Microsoft XPS, PCL 6, PDF 1.7
Processor family	ARM9
Sound power level (standby)	33 dB
Sound pressure level (printing)	50 dB
Sound pressure level (quiet mode)	45 dB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Cabling technology	10/100Base-T(X)
Security algorithms	APOP, SMTP-AUTH, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port 9100, IPP, FTP Server, SNMPv1/v2c/v3, HTTP Server, TFTP Client/Server, SMTP Client, ICMP, Web Services (Print/Scan), SNTP Client, POP3, IMAP4
Supported network protocols (IPv6)	NDP, RA, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port 9100, IPP, FTP Server, SNMPv1/v2c/v3, HTTP Server, TFTP Client/Server, SMTP Client, ICMPv6, Web Services (Print/Scan), SNTP Client, POP3, IMAP4
Direct printing	-
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1104 W
Power consumption (off)	0.08 W
Power consumption (standby)	60 W
Power consumption (PowerSave)	6.6 W
Power consumption (average operating)	510 W
Minimum storage drive space	500 MB
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Package depth	567 mm
Package width	517 mm
Package height	435 mm
Package weight	14200 g
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	409 mm
Width	398.5 mm
Height	316.5 mm
