Brother DCP-L5500DN How To Replace Drum Unit

- 4 -
5
Ga naar http://www.brother.com/original/index.html voor aanwijzingen over het terugsturen van gebruikte artikelen aan het Brother-verzamelprogramma. Als u het
gebruikte artikel niet terugstuurt, dient u dit te verwijderen conform de plaatselijke voorschriften en dit niet als huishoudelijk afval te behandelen. Voor meer informatie
neemt u contact op met de plaatselijke afvalmaatschappij.
[ Nederlands ] RESET DE TELLER VAN DE DRUMKIT
Zorg ervoor dat de machine ingeschakeld is.
<Voor HL-L5000D / HL-L5100DN(T) / HL-L5200DW(T) /
HL-L6200DW(T) / HL-L6250DN / HL-L6250DW>
(1) Zorg ervoor dat het frontdeksel open is.
(2) Houd OK ongeveer twee seconden ingedrukt om de optie
Drum weer te geven en druk vervolgens op OK.
(3) Druk op a om Herstel te selecteren.
(4) Sluit het frontdeksel.
<Voor HL-L6300DW(T) / HL-L6400DW(T) / DCP-L5500D /
DCP-L5500DN / DCP-L5600DN / DCP-L5650DN / DCP-L6600DW /
MFC-L5700DN / MFC-L5700DW / MFC-L5750DW / MFC-L5755DW /
MFC-L5800DW / MFC-L5900DW / MFC-L6700DW / MFC-L6750DW /
MFC-L6800DW / MFC-L6900DW>
(1) Sluit het frontdeksel.
(2) Druk op
om de fout te onderbreken.
(3) (Voor HL-modellen) Druk op
(Instell.) >
Apparaatgegevens > Levensduur onderd..
(Voor DCP- en MFC-modellen) Druk op (Instell.) >
Alle instell. > Machine-info >
Levensduur onderdelen.
(4)
(Voor HL-modellen) Druk op Levensduur drum tot de melding
op het aanraakscherm wijzigt en druk vervolgens op Ja.
(Voor DCP- en MFC-modellen) Druk op Drumeenheid tot de
melding op het aanraakscherm wijzigt en druk vervolgens op Ja.
(5) Druk op .
5
Visitare http://www.brother.com/original/index.html per le istruzioni sulla procedura di restituzione dei materiali di consumo usati al programma di raccolta Brother. Se non
si desidera restituire il materiale di consumo usato, smaltirlo in conformità alla legislazione locale, tenendolo separato dai riuti domestici. Per chiarimenti, contattare il
locale ufcio smaltimento riuti.
[ Italiano ] AZZERARE IL CONTATORE DEL GRUPPO TAMBURO
Accertarsi che la macchina sia accesa.
<Per HL-L5000D / HL-L5100DN(T) / HL-L5200DW(T) /
HL-L6200DW(T) / HL-L6250DN / HL-L6250DW>
(1) Accertarsi che il coperchio anteriore sia aperto.
(2) Tenere premuto OK per circa due secondi per visualizzare il
Gruppo tamburo e premere OK.
(3) Premere a per selezionare Reset.
(4) Chiudere il coperchio anteriore.
<Per HL-L6300DW(T) / HL-L6400DW(T) / DCP-L5500D /
DCP-L5500DN / DCP-L5600DN / DCP-L5650DN / DCP-L6600DW /
MFC-L5700DN / MFC-L5700DW / MFC-L5750DW / MFC-L5755DW /
MFC-L5800DW / MFC-L5900DW / MFC-L6700DW / MFC-L6750DW /
MFC-L6800DW / MFC-L6900DW>
(1) Chiudere il coperchio anteriore.
(2) Premere
per interrompere l’errore.
(3)
(Per i modelli HL) Premere (Im p.) > Info macchina >
Dur.res.parti.
(Per i modelli DCP e MFC) Premere (Im postaz.) >
Tutte le imp. > Info. macchina > Durata dei pezzi.
(4) (Per i modelli HL) Premere Vita tamburo no a che il
messaggio sul touchscreen non cambia, quindi premere Si.
(Per i modelli DCP e MFC) premere Tamburo no a che il
messaggio sul touchscreen non cambia, quindi premere Si.
(5) Premere
.
5
Visite http://www.brother.com/original/index.html para obtener instrucciones acerca de cómo devolver los consumibles usados al programa de recogida de Brother. Si no
desea devolver los consumibles usados, deséchelos según las normas locales, separándolos de los residuos domésticos. Si tiene dudas, consulte con las autoridades
locales.
[ Español ] REINICIE EL CONTADOR DE LA UNIDAD DE TAMBOR
Asegúrese de que el equipo está encendido.
<Para HL-L5000D / HL-L5100DN(T) / HL-L5200DW(T) /
HL-L6200DW(T) / HL-L6250DN / HL-L6250DW>
(1) Asegúrese de que la cubierta delantera está abierta.
(2) Pulse OK y manténgalo pulsado unos dos segundos para ir a
la opción Unidad de tambor y, a continuación, pulse OK.
(3) Pulse a para seleccionar Reconf.
(4) Cierre la cubierta delantera.
<Para HL-L6300DW(T) / HL-L6400DW(T) / DCP-L5500D /
DCP-L5500DN / DCP-L5600DN / DCP-L5650DN / DCP-L6600DW /
MFC-L5700DN / MFC-L5700DW / MFC-L5750DW / MFC-L5755DW /
MFC-L5800DW / MFC-L5850DW / MFC-L5900DW / MFC-L6700DW /
MFC-L6750DW / MFC-L6800DW / MFC-L6900DW>
(1) Cierre la cubierta delantera.
(2) Pulse
para interrumpir el error.
(3) (Para modelos HL) Pulse
(Ajustes (Cong) ) >
Información máquina (Inf. de la máquina) >
Vida útil piezas (Vida piezas).
(Para modelos DCP y MFC) Pulse
(Congurar
(Congurac) ) > Todos ajustes (Tod. cong.) >
Info. equipo > Vida útil de las piezas.
(4)
(Para modelos HL) Pulse Vida tambor hasta que el mensaje
de la pantalla táctil cambie y, a continuación, pulse Sí.
(Para modelos DCP y MFC) Pulse Tambor hasta que el
mensaje de la pantalla táctil cambie y, a continuación, pulse Sí.
(5) Pulse .
Voltooien
Fine
Finalizar

Brother DCP-L5500DN Specifications

General

N-up printing	2, 4, 9, 16, 25
Secure printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	10 ppm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scan drivers	ISIS, TWAIN
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Scan speed (black)	24 inch/min
Scan speed (color)	20 inch/min
Image formats supported	JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF, XPS
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	40 cpm
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	0 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7
Display	LCD
Control type	Touch
Product color	Black, Graphite
Display diagonal	3.7 \
Market positioning	Business
Email protocols	APOP, IMAP4, POP3, SMTP
Cabling technology	10/100Base-T(X)
Security algorithms	802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Online services supported	Box, Dropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, OneNote, Picasa
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3*, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4
Processor family	ARM
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	52 dB
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Mobile operating systems supported	Windows Phone, Windows RT
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth	520 mm
Package width	545 mm
Package height	641 mm
Package weight	19700 g
Power consumption (off)	1.6 W
Power consumption (sleep)	7.5 W
Power consumption (standby)	34 W
Power consumption (PowerSave)	390 W
Power consumption (average operating)	645 W
Energy Star Typical Electricity Consumption (TEC)	1.832 kWh/week
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	40 sheets
Certification	GS Mark
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	427 mm
Width	435 mm
Height	486 mm
