Brother DCP-L5500DN How To Replace Drum Unit

- 5 -
5
Visite http://www.brother.com/original/index.html para obter instruções de devolução de consumíveis usados através do programa de recolha da Brother. Se optar por
não devolver o consumível usado, elimine-o de acordo com os regulamentos de lixo locais, mantendo-o separado do lixo doméstico. Se tiver dúvidas, contacte os
serviços locais de tratamento de resíduos.
[ Português ] REINICIE O CONTADOR DA UNIDADE DO TAMBOR
Certique-se de que o equipamento está ligado.
<Para HL-L5000D / HL-L5100DN(T) / HL-L5200DW(T) /
HL-L6200DW(T) / HL-L6250DN / HL-L6250DW>
(1) Certique-se de que a tampa frontal está aberta.
(2) Prima e mantenha premido OK durante dois segundos para
que apareça Unidade Tambor e, de seguida, prima OK.
(3) Prima a para selecionar reset.
(4) Feche a tampa frontal.
<Para HL-L6300DW(T) / HL-L6400DW(T) / DCP-L5500D /
DCP-L5500DN / DCP-L5600DN / DCP-L5650DN / DCP-L6600DW /
MFC-L5700DN / MFC-L5700DW / MFC-L5750DW / MFC-L5755DW /
MFC-L5800DW / MFC-L5900DW / MFC-L6700DW / MFC-L6750DW /
MFC-L6800DW / MFC-L6900DW>
(1) Feche a tampa frontal.
(2) Prima
para interromper o erro.
(3)
(Modelos HL) Prima (Den.s) > Inform. equipamento >
Vida útil peç..
(Modelos DCP e MFC ) Prima (Denições) >
Den. todas > Info. eq uip. > Vida Útil das Peças.
(4) (Modelos HL) Prima Vida do tambor até a mensagem do
ecrã tátil mudar e, de seguida, prima Sim.
(Modelos DCP e MFC) Prima Tambor até a mensagem do
ecrã tátil mudar e, de seguida, prima Sim.
(5) Prima
.
5
Acesse o site da web http://www.brother.com/original/index.html para obter instruções de como devolver seus suprimentos usados para o programa de coleta da Brother.
Se optar por não devolver o seu suprimento usado, descarte-o de acordo com os regulamentos locais, mantendo-o separado do lixo doméstico. Se tiver alguma dúvida,
entre em contato com o escritório local responsável pelo descarte de lixo.
[ Português brasileiro ] REINICIE O CONTADOR DA UNIDADE DE CILINDRO
Conrme se o aparelho está ligado.
<Para HL-L5102DW / HL-L5202DW / HL-L6202DW>
(1) Conrme se a tampa frontal está aberta.
(2) Mantenha o botão OK pressionado por cerca de dois
segundos para exibir a opção Unid. Cilindro e pressione
OK.
(3) Pressione a para exibir a opção reset e zere o contador do
cilindro.
(4) Feche a tampa frontal.
<Para HL-L6402DW / DCP-L5502DN / DCP-L5602DN /
DCP-L5652DN / MFC-L5702DW / MFC-L5802DW / MFC-L5902DW /
MFC-L6702DW / MFC-L6902DW>
(1) Feche a tampa frontal.
(2) Pressione
para interromper o erro.
(3) (Para modelos HL) Pressione
(Congs) >
Info do Aparelho > Duração Peças.
(Para modelos DCP e MFC) Pressione (Congs) >
Todas cong. > Info. aparelho > Duração das Peças.
(4) (Para modelos HL) Pressione Cilindro-VIDA até que
a mensagem da tela touchscreen mude e, em seguida,
pressione Sim.
(Para modelos DCP e MFC) Pressione Cilindro até que
a mensagem da tela touchscreen mude e, em seguida,
pressione Sim.
(5) Pressione
.
5
Gå til http://www.brother.com/original/index.html for instruksjoner om hvordan du returnerer dine brukte rekvisita til Brothers innsamlingsprogram. Hvis du velger å ikke
returnere dine brukte rekvisita, kasserer du forbruksmateriellet i henhold til lokalt regelverk og holder det atskilt fra husholdningsavfall. Hvis du har noen spørsmål, kan du
ringe ditt lokale avfallskontor.
[ Norsk ] TILBAKESTILL TROMMELENHETENS TELLER
Sørg for at maskinen er slått på.
<For HL-L5000D / HL-L5100DN(T) / HL-L5200DW(T) /
HL-L6200DW(T) / HL-L6250DN / HL-L6250DW>
(1) Sørg for at frontdekselet er åpent.
(2) Trykk og hold nede OK i omtrent to sekunder for å vise
Trommelenhet-alternativet, og trykk deretter på OK.
(3) Trykk på a for å velge Reset.
(4) Lukk frontdekselet.
<For HL-L6300DW(T) / HL-L6400DW(T) / DCP-L5500D /
DCP-L5500DN / DCP-L5600DN / DCP-L5650DN / DCP-L6600DW /
MFC-L5700DN / MFC-L5700DW / MFC-L5750DW / MFC-L5755DW /
MFC-L5800DW / MFC-L5900DW / MFC-L6700DW / MFC-L6750DW /
MFC-L6800DW / MFC-L6900DW>
(1) Lukk frontdekselet.
(2) Trykk
for å stoppe feilen.
(3) (For HL-modeller) Trykk på
(Innstill.) >
Maskininformasjon > Delens levetid.
(For DCP- og MFC-modeller) Trykk på
(Innst.) >
Alle innst. > Maskininfo > Levetid for deler.
(4)
(For HL-modeller) Trykk på Trommel teller inntil meldingen
på berøringsskjermen endres, og trykk deretter på Ja.
(For DCP- og MFC-modeller) Trykk på Trommel inntil meldingen
på berøringsskjermen endres, og trykk deretter på Ja.
(5) Trykk på .
Concluir
Concluir
Fullfør

Brother DCP-L5500DN Specifications

General

N-up printing	2, 4, 9, 16, 25
Secure printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	10 ppm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scan drivers	ISIS, TWAIN
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Scan speed (black)	24 inch/min
Scan speed (color)	20 inch/min
Image formats supported	JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF, XPS
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	40 cpm
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	0 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7
Display	LCD
Control type	Touch
Product color	Black, Graphite
Display diagonal	3.7 \
Market positioning	Business
Email protocols	APOP, IMAP4, POP3, SMTP
Cabling technology	10/100Base-T(X)
Security algorithms	802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Online services supported	Box, Dropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, OneNote, Picasa
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3*, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4
Processor family	ARM
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	52 dB
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Mobile operating systems supported	Windows Phone, Windows RT
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth	520 mm
Package width	545 mm
Package height	641 mm
Package weight	19700 g
Power consumption (off)	1.6 W
Power consumption (sleep)	7.5 W
Power consumption (standby)	34 W
Power consumption (PowerSave)	390 W
Power consumption (average operating)	645 W
Energy Star Typical Electricity Consumption (TEC)	1.832 kWh/week
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	40 sheets
Certification	GS Mark
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	427 mm
Width	435 mm
Height	486 mm
