Application of
Disassembly
3 - 3
Main frame and Covers
Application o
f
Disassembly
Application of
Disassembly
1
Disassembly of Face plate assy
1.
Remove th
e screw (taptite, bin
d B M3X10) to remove th
e face plate cutter h
older and the NT lower
thread cutter from the face plate ass
y.
T
aptite, Bind B M3X10
NT lower thread cu
tter
Face plate assy
Face plate cutter holder
Taptite, bind B M3X10
60
62
