Application of
Disassembly
3 - 15
Feed unit
Application o
f
Disassembly
Application of
Disassembly
14.Remove the two screws (taptite, pan P (S/P W)
3X12
) to remove the two horizontal feed shaft pressers
from the feed holder. An
d remove the horizontal feed
shaft of feed arm
A sub assy from the feed holder.
T
aptite, Pan P
(S/P W) 3X12
Horizontal feed shaft presser
Horizontal feed shaft presser
Taptite, pan P (S/P W) 3X12
Horizontal feed shaft
Feed holder
Feed arm A sub assy
72
74
