5-17
Confidential
DF Document detection sensor No document Document set
DR First side document scanning
position sensor
No document Document set
AC ADF cover sensor ADF cover closed ADF cover open
C2 T2LT paper feed sensor
(When LT is in use)
Paper tray 2 closed Paper tray 2 open
P2 T2LT paper empty sensor
(When LT is in use)
No paper Paper set
C3 T3LT paper feed sensor
(When LT is in use)
Paper tray 3 closed Paper tray 3 open
P3 T3LT paper empty sensor
(When LT is in use)
No paper Paper set
E2 T2TT paper feed sensor TT paper tray 2 closed
and No paper
TT paper tray 2 open
and Paper set
D2 T2TT paper empty sensor No paper Paper set
E3 T3TT paper feed sensor TT paper tray 3 closed
and No paper
TT paper tray 3 open
and Paper set
D3 T3TT paper empty sensor No paper Paper set
E4 T4TT paper feed sensor TT paper tray 4 closed
and No paper
TT paper tray 4 open
and Paper set
D4 T4TT paper empty sensor No paper Paper set
E5 T5TT paper feed sensor TT paper tray 5 closed
and No paper
TT paper tray 5 open
and Paper set
D5 T5TT paper empty sensor No paper Paper set
J2 T2 JAM sensor No paper Paper set
J3 T3 JAM sensor No paper Paper set
J4 T4 JAM sensor No paper Paper set
J5 T5 JAM sensor No paper Paper set
AL TT balance sensor L With attachment No attachment
AR TT balance sensor R With attachment No attachment
LCD Sensor name
Detection status
With display No display
