Brother MFC-L5700DW Service Manual

5-21
Confidential
1.3.12 Set PC print functions (function code: 43)
<Function>
This function is used to change the settings of the various print functions summarized in the
table below.
<Operating Procedure>
(1) Press the [4], and then the [3] key in the initial state of maintenance mode. "Manual
Feed" is displayed on the LCD.
(2) Press the [▲] or [▼] key to display the function you want to change the setting of, and
press the [SET] key.
(3) For fixed parameters (On/Off, etc.), press the [▲] or [▼] key to display the setting you
want to apply, and press the [SET] key. For parameters requiring numerical value entry,
use the keypad to enter a numerical value directly, and press the [SET] key.
(4) When the [X] key is pressed, the machine returns to the initial state of maintenance
mode.
 Setting functions
LCD Description Set value Default
Manual Feed Manual feed setting On/Off Off
Resolution Print resolution 300/600/1,200 dpi 600 dpi
Toner Save Toner save mode setting On/Off Off
Density Print density level -6 to 6 0
JB-Can Time Time until host timeout after a job
is canceled
0 to 225 seconds 10 seconds
Sleep Time Time until sleep mode is entered 0 to 99 minutes 1 minute
Page Protection Page memory setting Off/Letter/A4/Legal/Auto Auto
Emulation Emulation (print language)
setting
Auto/HP/PS Auto
Auto I/F Time Interface open time setting 1 to 99 seconds 5 seconds
Media Type Paper type setting Thin/Plain/Thick/
Thicker/Transparency/
Recycled/Bond/
Envelopes/EnvThin/
EnvThick
Plain or Thin
Paper Size Image development area setting Letter/Legal/A4/
Executive/ISOB5/JISB5/
A5/ISOB6/A6/Monarch/
C5/COM10/DL/DLL/
A4Long/Postcard/Folio
Letter or A4
Copies Number of copies 1 to 99 copies 1 copy
Orientation Print direction setting Portrait/Landscape Portrait
P-Pos X-Offset Print position offset in X
(landscape) direction
-500 to 500 (1/300 dpi) 0 (1/300 dpi)
P-Pos Y-Offset Print position offset in Y (portrait)
direction
-500 to 500 (1/300 dpi) 0 (1/300 dpi)
Auto FF Auto Form Feed setting On/Off Off
Auto FF Time Time until Auto Form Feed
timeout
1 to 99 seconds 5 seconds
FF Surpress Blank page skip setting On/Off Off

Brother MFC-L5700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.7 \
Market positioning	Business
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PDF 1.3
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9.2 s
Copy speed (black, normal quality, A4)	42 cpm
Scan to	CIFS, Cloud, E-mail, E-mail Server, FTP, File, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Output color depth	24 bit
Input grayscale depth	16 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, JPG, PNG, TIF, TIFF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	DOCX, HTM, HTML, PDF, PPTX, RTF, TXT, XLS, XLSX, XML, XPS
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Cables included	Phone
Bundled software	Nuance PaperPort SE with OCR for Windows, Presto! PageManager with OCR for Mac
Included cartridge capacity (black)	2000 pages
Email protocols	APOP, IMAP4, POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Envelopes, Legal, Letter
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Card reader integrated	-
Sound pressure level (printing)	54 dB
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1248 W
Power consumption (off)	0.03 W
Power consumption (ready)	36 W
Power consumption (sleep)	8.4 W
Power consumption (printing)	630 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.567 kWh/week
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	426.7 mm
Width	434.4 mm
Height	485.1 mm
