Brother MFC-L5700DW Service Manual

5-37
Confidential
<Print type>
<Print page>
* Selectable only when the printing pattern is set to "K1%" or "K5%",
and the print type is not set to the manual feed slot.
<Number of pages per job> (Only for intermittent pattern printing)
*1
Selectable only when the SX is set as print type.
*2
Selectable only when the DX is set as print type.
*3
Fifth page will be printed as single-side printing.
LCD Description
SELECT:TRAY1 SX Single-side printing from paper tray 1
SELECT:TRAY1 DX Duplex printing from paper tray 1
SELECT:TRAY2 SX Single-side printing from paper tray 2
SELECT:TRAY2 DX Duplex printing from paper tray 2
SELECT:TRAY3 SX Single-side printing from paper tray 3
SELECT:TRAY3 DX Duplex printing from paper tray 3
SELECT:TRAY4 SX Single-side printing from paper tray 4
SELECT:TRAY4 DX Duplex printing from paper tray 4
SELECT:TRAY5 SX Single-side printing from paper tray 5
SELECT:TRAY5 DX Duplex printing from paper tray 5
SELECT:MP SX Single-side printing from MP tray
SELECT:MP DX Duplex printing from MP tray
SELECT:AUTO SX Single-side printing to automatically selected tray
SELECT:AUTO DX Double-side printing to automatically selected tray
LCD Description
SELECT:1PAGE 1-page printing
SELECT:CONTINUE Continuous printing
SELECT:JOB
Intermittent printing per job
*
LCD Description
SELECT:1P/JOB
Prints 1 page per job
*1
SELECT:2P/JOB
Prints 2 pages per job
*1
SELECT:5P/JOB
Prints 5 pages per job
*1
SELECT:10P/JOB
Prints 10 pages per job
*1
SELECT:2I/JOB
Prints 2 images per job
*2
SELECT:5I/JOB
Prints 5 images per job
*2 *3
SELECT:10I/JOB
Prints 10 images per job
*2
SELECT:20I/JOB
Prints 20 images per job
*2

Brother MFC-L5700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.7 \
Market positioning	Business
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PDF 1.3
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9.2 s
Copy speed (black, normal quality, A4)	42 cpm
Scan to	CIFS, Cloud, E-mail, E-mail Server, FTP, File, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Output color depth	24 bit
Input grayscale depth	16 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, JPG, PNG, TIF, TIFF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	DOCX, HTM, HTML, PDF, PPTX, RTF, TXT, XLS, XLSX, XML, XPS
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Cables included	Phone
Bundled software	Nuance PaperPort SE with OCR for Windows, Presto! PageManager with OCR for Mac
Included cartridge capacity (black)	2000 pages
Email protocols	APOP, IMAP4, POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Envelopes, Legal, Letter
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Card reader integrated	-
Sound pressure level (printing)	54 dB
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1248 W
Power consumption (off)	0.03 W
Power consumption (ready)	36 W
Power consumption (sleep)	8.4 W
Power consumption (printing)	630 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.567 kWh/week
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	426.7 mm
Width	434.4 mm
Height	485.1 mm
