Brother MFC-L5700DW Service Manual

2-16
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
6902
Rechecking the error after the power
switch was turned OFF and then ON
again because an error was detected
in the fuser unit. (This message is
displayed for approximately 15
minutes when the machine is
restarted after error code 6901 has
occurred.)
2-49 7100
The eject sensor remains ON (paper
pass detected) even after the
registration rear sensor detected the
end of paper pass.
2-51
6A00
Detected discharge that may be
attributable to dirty corona wire on the
drum unit.
2-50
7101 ―
6B01 ― 7102 ―
6B02 ― 7103 ―
6B03 ― 7104 ―
6B04 ― 7105 ―
6B0A ― 7106 ―
6C01 ― 7200
When feeding from the MP tray, the
registration rear sensor does not
detect paper pass within the specified
time after the registration front sensor
detected paper pass.
2-52
6C02 ― 7201 ―
6C03 ― 7300 ―
6C04 ― 7301
When printing from the paper tray 1,
the T1 paper feed sensor does not
detect paper pass within the specified
time while the T1 paper empty sensor
detects some paper set.
2-53
6D00
Detected more LTs than connectible
limit.
2-50 7302
When printing from the paper tray 1,
the registration front sensor does not
detect paper pass within the specified
time after the T1 paper feed sensor
detected paper pass.
2-53
6E00 ― 7400 ―
6F00
Detected irregular power supply for
less than 100 times.
2-50 7401
When printing from the paper tray 2, the
T2(LT or TT) paper feed sensor does not
detect paper pass within the specified
time while the T2(LT or TT) paper empty
sensor detects some paper set.
2-54
7000
The eject sensor does not detect
paper pass after the registration rear
sensor detected the paper pass.
2-51 7402
When printing from the paper tray 2,
the registration front sensor or the
T2TT jam sensor does not detect
paper pass within the specified time
after the T2(LT or TT) paper feed
sensor detected paper pass.
2-55
7001 ― 7500 ―
7002 ― 7501
When printing from the paper tray 3, the
T3(LT or TT) paper feed sensor does not
detect paper pass within the specified
time while the T3(LT or TT) paper empty
sensor detects some paper set.
2-56
7003 ― 7502
When printing from the paper tray 3,
the registration front sensor or the T2/
T3TT jam sensor does not detect
paper pass within the specified time
after the T3(LT or TT) paper feed
sensor detected paper pass.
2-57
7004 ― 7601
When printing from the paper tray 4, the
T4(LT or TT) paper feed sensor does not
detect paper pass within the specified
time while the T4(LT or TT) paper empty
sensor detects some paper set.
2-58

Brother MFC-L5700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.7 \
Market positioning	Business
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PDF 1.3
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9.2 s
Copy speed (black, normal quality, A4)	42 cpm
Scan to	CIFS, Cloud, E-mail, E-mail Server, FTP, File, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Output color depth	24 bit
Input grayscale depth	16 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, JPG, PNG, TIF, TIFF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	DOCX, HTM, HTML, PDF, PPTX, RTF, TXT, XLS, XLSX, XML, XPS
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Cables included	Phone
Bundled software	Nuance PaperPort SE with OCR for Windows, Presto! PageManager with OCR for Mac
Included cartridge capacity (black)	2000 pages
Email protocols	APOP, IMAP4, POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Envelopes, Legal, Letter
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Card reader integrated	-
Sound pressure level (printing)	54 dB
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1248 W
Power consumption (off)	0.03 W
Power consumption (ready)	36 W
Power consumption (sleep)	8.4 W
Power consumption (printing)	630 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.567 kWh/week
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	426.7 mm
Width	434.4 mm
Height	485.1 mm
