2-35
Confidential
20 01 Unable to detect flag field. 2-123
20 02 Carrier was OFF for 200 ms or longer. 2-123
20 03 Abort detected ("1" in succession for 7 bits or more). 2-123
20 04 Overrun detected. 2-123
20 05 A frame received for 3 seconds or more. 2-123
20 06 CRC error in answerback. 2-123
20 07 Echo command received. 2-123
20 08 Invalid command received. 2-123
20 09
Command ignored in document setting or damping-out at
turn-around transmission.
2-123
20 0A T5 time-out error 2-123
20 0B CRP received. 2-123
20 0C EOR or NULL received. 2-123
20 0D
Corresponding command not received although the FIF
command sending bit is ON.
2-123
20 0E EOR command received. 2-123
20 13
Line disconnected without receiving DCN after receiving
the last page.
(After receiving EOP and sending CFR, received BYE
before receiving DCN.) (T38)
2-123
32 01
Remote terminal only with V.29 capability in 2,400 or 4,800
bps transmission.
2-123
32 02 Remote terminal not ready for polling. 2-123
32 10
Remote terminal not equipped with password function or
its password switch is OFF.
2-123
32 11
Remote terminal not equipped with or not ready for
confidential mailbox function.
2-123
32 12
Remote terminal not equipped with or not ready for relay
broadcasting function.
2-123
32 13 No confidential mail in the remote terminal. 2-123
32 14
Available memory space of the remote terminal is less
than that required for reception of confidential mails or
relay broad-casting instruction.
2-123
32 15
Remote terminal not equipped with Cipher receiving
function.
2-123
32 16 Remote terminal not equipped with SEP function. 2-123
32 17 Remote terminal not equipped with SUB function. 2-123
32 18 Remote terminal not equipped with color function. 2-123
40 02 Illegal coding system requested. 2-123
40 03 Illegal recording width requested. 2-123
Code 1 Code 2 Cause Refer to:
