Brother MFC-L6800DW How To Replace Drum Unit

- 8 -
5
Przejdź do strony http://www.brother.com/original/index.html, aby uzyskać informacje dotyczące zwrotu zużytych materiałów eksploatacyjnych w programie zbiórki
Brother. Jeśli nie zdecydujesz się na zwrot zużytego materiału eksploatacyjnego, prosimy pozbyć się go zgodnie z lokalnymi przepisami i nie wyrzucać ich do śmieci.
W razie wątpliwości należy skontaktować się z miejscowym organem nadzorującym gospodarkę odpadami.
[ Polski ] ZRESETUJ LICZNIK ZESPOŁU BĘBNA
Upewnij się, że urządzenie jest włączone.
<Dla HL-L5000D / HL-L5100DN(T) / HL-L5200DW(T) /
HL-L6200DW(T) / HL-L6250DN / HL-L6250DW>
(1) Upewnij się, że przednia pokrywa jest otwarta.
(2) Naciśnij i przytrzymaj przycisk OK przez około dwie sekundy,
aby wyświetlić komunikat Zespół bębna, a następnie
naciśnij przycisk OK.
(3) Naciśnij a, aby wybrać opcję reset.
(4) Zamknij pokrywę przednią.
<Dla HL-L6300DW(T) / HL-L6400DW(T) / DCP-L5500D /
DCP-L5500DN / DCP-L5600DN / DCP-L5650DN / DCP-L6600DW /
MFC-L5700DN / MFC-L5700DW / MFC-L5750DW / MFC-L5755DW /
MFC-L5800DW / MFC-L5900DW / MFC-L6700DW / MFC-L6750DW /
MFC-L6800DW / MFC-L6900DW>
(1) Zamknij pokrywę przednią.
(2) Naciśnij
, aby naprawić błąd.
(3)
(W przypadku modeli HL) Naciśnij (Ustaw.) >
Inform. o urządz. > Zużycie części.
(W przypadku modeli DCP i MFC) Naciśnij (Ustawienia) >
Ustawienia > Inf. o urządz. > Trwałość części.
(4) (W przypadku modeli HL) Naciskaj Zużycie bębna, aż
zmieni się komunikat na ekranie dotykowym, a następnie
naciśnij Tak.
(W przypadku modeli DCP i MFC) Naciskaj Bęben, aż zmieni
się komunikat na ekranie dotykowym, a następnie naciśnij
Tak.
(5) Naciśnij
.
5
Отидете на http://www.brother.com/original/index.html за инструкции относно връщането на използвани консумативи по програмата за тяхното събиране
от Brother. Ако изберете да не връщате използваните консумативи, моля, изхвърляйте ги в съответствие с местните разпоредби, отделно от битовите
отпадъци. Ако имате въпроси, обадете се в местния пункт за вторични суровини.
[ Български ] НУЛИРАЙТЕ БРОЯЧА НА МОДУЛА НА БАРАБАНА
Уверете се, че устройството е включено.
<За HL-L5000D / HL-L5100DN(T) / HL-L5200DW(T) /
HL-L6200DW(T) / HL-L6250DN / HL-L6250DW>
(1) Уверете се, че предният капак е отворен.
(2) Натиснете и задръжте OK за около две секунди, за да се
покаже Барабан, след което натиснете OK.
(3) Натиснете a, за да изберете Reset.
(4) Затворете предния капак.
<За HL-L6300DW(T) / HL-L6400DW(T) / DCP-L5500D /
DCP-L5500DN / DCP-L5600DN / DCP-L5650DN / DCP-L6600DW /
MFC-L5700DN / MFC-L5700DW / MFC-L5750DW / MFC-L5755DW /
MFC-L5800DW / MFC-L5900DW / MFC-L6700DW / MFC-L6750DW /
MFC-L6800DW / MFC-L6900DW>
(1) Затворете предния капак.
(2) Натиснете
, за да прекъснете грешката.
(3) (За HL модели) Натиснете
(Настройки) >
Инфор.за устр
> Живот на части.
(За DCP и MFC модели) Натиснете (Настройки) >
Всички настр.
> Инфор.за маш. > Живот на части.
(4) (За HL модели) Натискайте Живот барабан, докато
съобщението на сензорния екран не се промени, след
което натиснете Да.
(За DCP и MFC модели) Натискайте Барабан, докато
съобщението на сензорния екран не се промени, след
което натиснете Да.
(5) Натиснете
.
5
Vizitaţi http://www.brother.com/original/index.html pentru instrucţiuni legate de modul în care puteţi returna consumabilele uzate în cadrul programului de colectare
Brother. Dacă optaţi pentru a nu returna consumabilele uzate, vă rugăm să le eliminaţi în conformitate cu reglementările locale, separându-le de deşeurile menajere.
Dacă aveţi întrebări, contactaţi centrul de colectare local.
[ Română ] RESETAŢI CONTORUL UNITĂŢII DE CILINDRU
Vericaţi dacă aparatul este pornit.
<Pentru HL-L5000D / HL-L5100DN(T) / HL-L5200DW(T) /
HL-L6200DW(T) / HL-L6250DN / HL-L6250DW>
(1) Asiguraţi-vă că este deschis capacul frontal.
(2) Apăsaţi şi menţineţi apăsat butonul OK timp de aproximativ
două secunde pentru a aşa Unitate cilindru, iar apoi
apăsaţi pe OK.
(3) Apăsaţi a pentru a selecta Reset.
(4) Închideţi capacul frontal.
<Pentru HL-L6300DW(T) / HL-L6400DW(T) / DCP-L5500D /
DCP-L5500DN / DCP-L5600DN / DCP-L5650DN / DCP-L6600DW /
MFC-L5700DN / MFC-L5700DW / MFC-L5750DW / MFC-L5755DW /
MFC-L5800DW / MFC-L5900DW / MFC-L6700DW / MFC-L6750DW /
MFC-L6800DW / MFC-L6900DW>
(1) Închideţi capacul frontal.
(2) Apăsaţi
pentru a întrerupe eroarea.
(3) (Pentru modelele HL) Apăsaţi
(Setări) >
Info echipament > Durată func. comp..
(Pentru modelele DCP şi MFC) Apăsaţi (Setări) >
Toate setările > Info. aparat >
Funcţionare componente.
(4) (Pentru modelele HL) Apăsaţi Viaţă cilindru până când
mesajul de pe ecranul tactil se modică, iar apoi apăsaţi Da.
(Pentru modelele DCP şi MFC) Apăsaţi Cilindru până când
mesajul de pe ecranul tactil se modică, iar apoi apăsaţi Da.
(5) Apăsaţi
.
Zakończ
Край
Finalizare

Brother MFC-L6800DW Specifications

General

N-up printing	2, 4, 9, 16, 25
Secure printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Manual
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	46 ppm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Scan speed (black)	24 inch/min
Scan speed (color)	20 inch/min
Image formats supported	JPG
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (color)	17 ppm
Document formats supported	PDF
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9.5 s
Copy speed (black, normal quality, A4)	46 cpm
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Digital sender	No
Printing colors	Black
Maximum duty cycle	125000 pages per month
Recommended duty cycle	0 - 7500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, PCL 6, PDF 1.7, PostScript 3
Display	LCD
Control type	Touch
Product color	White
Display diagonal	4.85 \
Market positioning	Business
Email protocols	SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-PEAP, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, LEAP, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Box, Dropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, OneNote
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS name resolution, DNS resolver, mDNS, LLMNR responder, LPR/ LPD, custom Raw Port/Port9100, IPP/IPPS, FTP server, TELNET server, HTTP/HTTPS server, TFTP client en server, SMTP client, SNMPv1/v2c/ v3, ICMP, web services (printen), CIFS client, SNTP client, LDAP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, custom raw port/ Port9100, IPP/IPPS, FTP server, TELNET server, HTTP/HTTPS server, TFTP client en server, SMTP client, SNMPv1/v2c, ICMPv6, web services (print), CIFS client, SNTP client, LDAP
Processor family	ARM
Card reader integrated	-
Sound power level (standby)	35 dB
Sound pressure level (copying)	57 dB
Sound pressure level (quiet mode)	53 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Mobile operating systems supported	Windows Phone, Windows RT
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Standard interfaces	Ethernet, NFC, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth	526 mm
Package width	599 mm
Package height	659 mm
Package weight	22900 g
Power consumption (off)	1.6 W
Power consumption (sleep)	8 W
Power consumption (standby)	34 W
Power consumption (PowerSave)	390 W
Power consumption (average operating)	745 W
Energy Star Typical Electricity Consumption (TEC)	2.285 kWh/week
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Paper input type	Paper tray
Total input capacity	520 sheets
Total output capacity	250 sheets
Certification	GS Mark
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	427 mm
Width	495 mm
Height	518 mm
