BROWN 484 - Page 27

27
Bolt List All Models
A
B
C
D
I
G
H
J
K
L
E
A 3/4 X 7-1/2” Bolt, Lock washer & Nut A-Frame, Brace and Toggle Mount
B 3/4 X 2” Bolt, Lock washer & Nut (460 & 472) A-Frame Mount
3/4 X 7-1/2” Bolt, Lock washer & Nut (484) A-Frame Mount
C 1/2 X 2-1/2” Bolt & Lock nut Deector Mount
D 3/8 X 1-1/4” Plow bolt, lock washer & Nut Slide Mount
E 5/16 X 3/4” Bolt & Lock nut Manual Tube Mount
F 3/4 X 2-1/2” Bolt, Lock washer & Nut (460 & 472) Brace & Tail wheel Mount
3/4 X 5-1/4” Bolt, Lock washer & Nut (484) Brace and Tail wheel Mount
G 1 X 8” Bolt & Lock nut Axle Bolt
H 1/2 X 1” Fine Bolt & Lock washer Hub Mount
I 1/2 X 2-1/2” Roll Key Fork - Collar Mount
J 3/4 X 18” Pin w/ Lynch pin & Flat washer (460 & 472) Height Adjustment
3/4 X 5-1/4” Bolt, Lock washer & Nut (484) Height Adjustment
K 3/4 X 3” Bolt ne, Nut & Lock nut Gear box mount
L 3/8 X 3/4” Bolt, Flat & Lock washer Shield Bracket Mount
M 3/8 X 1” Bolt, Flat & Lock washer Shield Mount
M
