Replacement Parts
31
Tailwheel Assembly (continued)
Ref. No. Part No. Description
1 67-S Spacer (2 - req. per tailwheel)
2 64-T Seal (2 req. per tailwheel)
3 65-T Bearing (2 req. per tailwheel)
4 65-C Cup (2 req. per tailwheel)
5 67T-A Complete tailwheel hub assembly
6 4-024 Height adjustment pin with clips
7 4-014
4-015
4-016
460: Tailwheel arm with fork holder
472: Tailwheel arm with fork holder
460D, 472D, 484: Tailwheel arm with fork holder
8 4-032 Complete tailwheel assembly
9 61-D Roll pin
10 61-C Collar
11 4-013 Fork
NP 4-013A Fork, Collar and Roll Pin Assembly
12 4-033 Axle
13 4-034 Axle nut
16 69-A Tire and wheel assembly
