BROWN 484 - Replacement Parts: 120 HP Gearbox Details

35
Replacement Parts
120HP Gearbox (continued)
Ref. No. Part No. Qty. Description
1 235-0003 1 Housing
2 235-0105 1 Input Cap Gasket Kit
3 235-0018 2 Bearing Assembly, Input
4 235-0005 1 Input Shaft
5 235-0019 1 Retaining Ring
6 235-0110 1 Shim Kit
7 235-0007 1 19 Tooth Gear, Input
8 235-0006 2 Spacer
10 WHD-202-20 1 Input Oil Seal
11 235-0004 1 Input Cap
12 235-0100 1 Output Cap Gasket Kit
13 235-0017 1 13 Tooth Gear, Output
15 235-0016 2 Bearing Assembly, Output
16 235-0015 1 Output Shaft
18 235-0013 1 Output Oil Seal
19 235-0014 1 Output Cap
20 TC-134F 1 1” - 14 Flanged Hex Nut
NP TC-135 1 Cotter Pin
NP 235-0001 1 120 HP Gearbox Assembly Complete
NP 235-0022 1 Vent Plug
NP 235-0021 2 Drain Plug
NP 235-0031 2 QT. Lubricant, Quart, Cotton Picker Spindle
