turning while unscrewing the opposite side
(See Figure 9).
Remove the retaining nut and screw from
the receiver.
With the gun inverted (trigger guard up),
grasp the trigger guard and pull it up,
forward and out from the receiver (See
Figure 10). DO NOT DISASSEMBLE THE
TRIGGER GROUP BEYOND THIS POINT.
Perform all cleaning with the trigger group
kept intact as an assembly.
REMOVING THE BREECHBLOCK — Normal
procedure is to remove the trigger group first, as
explained previously.
36
