Broyhill BANCROFT A102015331 - Step 11: Installing Big Roof Small Beams

Broyhill BANCROFT A102015331
26 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
19/26
STEP 11
Assemble the Big Roof Small
Beam(N1)&(N2) to Beam Connector 1(P)
with bolts(H1), Assemble the Big Roof Small
Beam(N1)&(N2) to Beam Connector 2(Q)
with bolts(H1), tighten by wrench (HW1).
