916 i TYPE C24
Figure 2: Engine Components
1
Propeller gear box
2 ECU
3 Fusebox 4 Intercooler
5 Intercooler 6 Airbox
7
Wiring harness
8
Turbocharger
9 Air baffle
10
Electric starter
11 Oil tank
12
Oil filter
13
Flange for governor
14
Flange for governor
Page 7-4
December 01 2023
BRP-Rotax Effectivity: 916 i A / C24
Edition 0 / Rev. 1
