BRP ROTAX 916 i A Series User Manual

7.5) Electric system
This System is responsible for supplying the Engine Manage-
ment System (EMS) and the Airframe with electrical power. It
consists of the Fusebox with Regulators and the Internal
Generators.
916 i TYPE A
Figure 9: Internal power supply
1 Stator 2 Fusebox
Page 7-10
December 01 2023
BRP-Rotax Effectivity: 916 i A / C24
Edition 0 / Rev. 1
