BRU EL 6120 LA++ - Connecting to the drain; Adjusting the feet; Electrical connection

46 / EN
Washing Machine / User’s Manual
2.5 Connecting to the drain
• Theendofthedrainhosemustbedirectlyconnectedto
thewastewaterdrainortothewashbasin.
A
warning: Yourhousewillbefloodedifthehosecomes
outofitshousingduringwaterdischarge.Moreover,there
isriskofscaldingduetohighwashingtemperatures!
Topreventsuchsituationsandtoensuresmoothwater
intakeanddischargeofthemachine,fixtheendofthe
dischargehosetightlysothatitcannotcomeout.
• Thehoseshouldbeattachedtoaheightofatleast40
cm,and100cmatmost.
• Incasethehoseiselevatedafterlayingitonthefloor
levelorclosetotheground(lessthan40cmabovethe
ground),waterdischargebecomesmoredifficultandthe
laundrymaycomeoutexcessivelywet.Therefore,follow
theheightsdescribedinthefigure.
100cm
40cm
• Topreventflowingofdirtywaterbackintothemachine
andtoallowforeasydischarge,donotimmersethehose
endintothedirtywaterordonotdriveitinthedrainmore
than15cm.Ifitistoolong,cutitshort.
• Theendofthehoseshouldnotbebent,itshouldnotbe
steppedonandthehosemustnotbepinchedbetween
thedrainandthemachine.
• Ifthelengthofthehoseistooshort,useitbyadding
anoriginalextensionhose.Lengthofthehosemay
notbelongerthan3.2m.Toavoidwaterleakfailures,
theconnectionbetweentheextensionhoseandthe
drainhoseoftheproductmustbefittedwellwithan
appropriateclampasnottocomeoffandleak.
2.6 Adjusting the feet
A
warning: Inordertoensurethattheproductoperates
moresilentlyandvibration-free,itmuststandleveland
balancedonitsfeet.Balancethemachinebyadjusting
thefeet.Otherwise,theproductmaymovefromitsplace
andcausecrushingandvibrationproblems.
1.Loosenthelocknutsonthefeetbyhand.
2.Adjustthefeetuntiltheproductstandsleveland
balanced.
3.Tightenalllocknutsagainbyhand.
A
warning: Donotuseanytoolstoloosenthelocknuts.
Otherwise,theywillgetdamaged.
2.7 Electrical connection
Connecttheproducttoagroundedoutletprotectedbya16
Afuse.Ourcompanyshallnotbeliableforanydamages
thatwillarisewhentheproductisusedwithoutgroundingin
accordancewiththelocalregulations.
• Connectionmustcomplywithnationalregulations.
• Powercableplugmustbewithineasyreachafter
installation.
• Ifthecurrentvalueofthefuseorbreakerinthehouseis
lessthan16Amps,haveaqualifiedelectricianinstalla
16Ampfuse.
• Thevoltagespecifiedinthe"Technicalspecifications"
sectionmustbeequaltoyourmainsvoltage.
• Donotmakeconnectionsviaextensioncablesormulti-
plugs.
B
warning: Damagedpowercablesmustbereplacedby
theAuthorizedServiceAgents.
Transportation of the product
1.Unplugtheproductbeforetransportingit.
2.Removewaterdrainandwatersupplyconnections.
3.Drainallwaterthathasremainedintheproduct.(SEE
5.5)
4.Installtransportationsafetyboltsinthereverseorderof
removalprocedure;(SEE2.3)
C
Nevermovetheproductwithoutthetransportationsafety
boltsproperlyfixedinplace!
A
warning: Packagingmaterialsaredangeroustochildren.
Keeppackagingmaterialsinasafeplaceawayfrom
reachofthechildren.
