Bruderer BBV 190/85 - Replacement and Adjustment of Feed Rollers and Clamping Bar; Preparations for Replacement and Adjustment

BSTA 180 – 500 BBV 190/85
BBV 190/85H
1
Replacement and Adjustment of the feed rollers and the clamping bar
Preparations:
1. Remove the guard plate 12206.00.0.00.
2. Remove the cover sheet.
3. Set the feed length to maximum feed length.
4. Turn off or disconnect the oil pump.
5. Jump the oil pressure switch if necessary.
6. Set the selector switch to “break open” position, so that the
machines’ eccentric shaft can be turned manually.
