Acquisition Front-end Type 2825
Service Manual
Brüel & Kjær
0− 4
7. Mechanical Parts
.......................................................................................................... 7–1
7.1 Dismantling Procedure............................................................................................... 7–2
Removing the Power Supply.................................................................................. 7–2
Removing the Backplane ....................................................................................... 7–3
7.2 Mains Switch and Fuseholder.................................................................................... 7–3
7.3 Fan Assembly UH1022............................................................................................... 7–4
7.4 Mechanical Parts List................................................................................................. 7–4
