4 TECHNICAL DATA AND DISPOSAL NOTES
SPECIFICATION
Peak Force: Pitch: 100 N / 22.5 lbs
Roll: 5 Nm / 3.7 lb-
Travel: Pitch: 150 mm / 5.9 in
Roll: +/- 90°
Yoke Handle: BRUNNER Beechcra style
with 10 buttons and Display
Optional: without yoke handle
Interface: USB (USB-2 Type-B)
Ethernet (RJ45),
CAN (RJ45)
Noise Levels: < 40dB(A)
Power: 400W peak (no fan)
Operating-Voltage: 90-255 VAC 50/60Hz (IEC5)
Weight: 6.3 kg / 13.9 lb
DISPOSAL NOTES
The device contains reusable materials and should be disposed of properly, not simply with unsorted
household refuse. Devices which are no longer needed must be disposed of in a professional and
appropriate way, in accordance with the current local regulations and laws.
DIMENSIONS
1,5
30,8
41
32
257,27
263,63
4
14,56
210
220
235
19,25 366,5
405
17,5
20
100
143 (max. 293)
87,28
55,55
149,31
402
5
,
5
4 -
38,5 328
