ENGLISH UNPACKING THE SOFA
& ATTACHING THE SIDE PARTS
Please remove the foil and cardboard from
your Bruno sofa bed and place it at its des-
tination
Fold out the lying surface in order to screw
on the side parts.
Please position the assembly aids under the
four corners of the centre part.
1. 2.
Now place the armrests on the side walls of
the side panels of the sofa.
Attention: For the “Classic” model, please
assemble the feet first, see the following
page.
Screw on both armrests with four Allen
screws and four washers using the ratchet
provided. Do not fully tighten the screws
until all screws are already slightly tightened.
Important: Please tighten the screws as
shown in the order 1 to 4.
3.
4.
TOOLS AND SCREWS
Included in the delivery are:
4 x Felt platelets for the wooden
feet or metal rails
(for the armrest Classic)
1 x Ratchet with matching
bit attachment
4 x Set-up aids
1 x Unfolding aid
(pre-assembled)
12 x Washers
12 x Allen screws:
8 pcs. for the side parts and
4 pcs. for the metal rails
(for the armrest Classic)
Two people are needed for the assembly.
The duration of the assembly is about 20–30 minutes and no manual skills are necessary.
Assemble the sofa in the room where you wish for it to remain. Assemble the sofa on a clean
and soft surface. An Allen key is included in the delivery. You do not need any other tools.
1
4
2
3
To Next Page
