BRUNSWICK INSTALLATION MANUAL PAGE 15
EDINBURGH
RAIL & APRON ASSEMBLY
CONTINUED
FIGURE FIVE
Step #13: Position the two side pockets and four corner
pockets into their respective pocket openings. Fit and
attach each pocket using four nails per pocket. Secure
straps on all four corner pockets to the slate frame
material as required.
FIGURE FIVE
FIGURE SIX
Step #14: Thoroughly brush the area on which the bed spot is to
be applied. Position the bed spot and rmly roll a ball over the spot
to achieve a good bond.
NOTE: Bed spots are self-adhesive. Bed spots can be
applied at both head and foot end of the table, or just the
foot end, whichever is preferred.
FIGURE SIX
