Brute Force UX1 - Page 14

ASSEMBLY STEP 5
- 13 -
No. Description Notes Qty
6
43
44
45
46
47
48
49
50
Flat washer
Weight stack rubber pad
Weight stack
Stainless steel guide rod
Selector rod
Cylindrical pin
Magnetic pull pin
Weight stack pulley
Hexagon bolt
Ø10
Ø60*Ø27*42
100kg
-
Ø25
10*60
10*100
-
M10*95
4
4
2
4
2
2
2
2
4
50
6
49
45
46
47
48
44
43
