Brute Force UX1 - Page 16

ASSEMBLY STEP 6
- 15 -
No. Description Notes Qty
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
Long smith machine guide rod
Safety hook left
Sliding tube left
Smith machine bar
Smith machine bar sleeve
Sliding tube right
Safety hook right
Long smith machine guide rod rubber pad lower
Long smith machine guide rod rubber pad upper
Adjustable setting lever
Aluminium cover
Fixing sleeve
Grub screw
Button head socket screw
Spring washer
Flat washer
Button head bolt
Spring washer
Snap lock collar
Ø25*1850
-
-
-
-
-
-
Ø60*Ø26*45
Ø60*Ø26*45
M12*32
Ø50*Ø19*Ø11
Ø45*Ø25.5*Ø35
M8*10
M12*40
Ø12
Ø12
M10*20
Ø10
Ø80*Ø50*49
2
1
1
1
2
1
1
2
2
1
1
2
2
2
2
2
1
1
2
54
62
63
51
55
66
65
64
69
56
59
57
58
52
67
68
61
53
60
