Brute Force UX1 - Page 18

ASSEMBLY STEP 7
- 17 -
No. Description Notes Qty
4
5
6
70
71
72
73
74
75
76
27
78
79
Hexagon bolt
Lock nut
Flat washer
Pulley
Hexagon bolt
Floating pulley bracket
Pulley
Sleeve
Cable
Carabena
Hexagon bolt
Pulley
Cable
M10*75
M10
Ø10
Ø19
M10*45
-
Ø50
Ø20*16*10.5*20.5
Ø5*4095 bulb
-
M10*25
Ø75
-
4
18
28
8
12
2
4
8
2
2
2
4
2
76
79
78 5
70
75
6
72
74
4
73
27
71
73
4
5
74
70
79
70
78
71
