ASSEMBLY STEP 1

ASSEMBLY STEP 1 INSTRUCTIONS

- 6 -

1. Connect lower connection frame (1) with upright frame right (3) and upright frame left (7)

with M10*75 hexagon bolt (4), Ø10 flat washer (6), M10 lock nut (5).

2. Connect upper connection frame (2) with upright frame right (3) and upright frame left (7)

with M10*75 hexagon bolt (4), Ø10 flat washer (6), M10 lock nut (5).
