ASSEMBLY STEP 2
- 7 -
17
9
15
12
8
13
16
5
14
11
10
13
6
14
4
No. Description Notes Qty
4
5
6
8
9
10
11
12
13
14
15
16
17
Hexagon bolt
Lock nut
Flat washer
Upper side connection frame right
Upper side connection frame left
Side connection frame right
Front connecting frame right
Inner shaft
Hexagon bolt
Large flat washer
Lifting bolt
Side connecting frame left
Upper side connecting frame left
M10*75
M10
Ø10
-
-
-
-
Ø20*85
M10*20 (thin head)
Ø30*Ø10*3
M10
-
-
8
8
16
1
2
1
2
4
6
8
2
1
1
